Single Beam Infrared Radiation Detector Automatic Door Light Sensor Burglar Alarm Infrared Alarm Detector

Infrared Detector designed for automatic door systems. It functions as an outdoor warning device to detect movement and trigger alarms.

• Compatibility: Automatic Door Systems
• Material: PC
• Key feature: Anti-glare and weather-resistant
• Detection Range: 10-20m
• Voltage: DC 12-24V
• Outdoor warning distance: 10m
• Indoor warning distance: 20m
• Induction speed: 50ms
• Alarm output: Normally closed and normally open (NC&NO)
• Contact capacity: AV/DC 30V/0.5mA
• Alarm linkage: Yes
• Working voltage: DC 12-24V
• Shell material: PC
• Product size: 7.6x4.9x2.9cm
• Anti-glare up to 50,000 LUX
• Built-in automatic adjustment of strong light filtering system
• All-weather integrated structure, fully sealed rainproof and dustproof
• Automatically increases sensitivity in dense fog or bad weather (AGC circuit)
• High level of RFI/EMI resistance
• Unique digital filter circuit design
• High-power transmitting device, photographic margin up to 90%
• High-power infrared receiving tube, low-power processing technology
• Lightning protection circuit design
• Rain cover design
• C type relay output
• Adjustable beam interception period
• Professional anti-interference optical cover
