Product details
The JDiag 6-30V Electrical Detector is designed for vehicle system diagnosis. It detects voltage, resistance, and diode in vehicle electrical systems.
- Product type: Electronic Test
- Compatibility: vehicle systems
- Voltage range: 0.1~70V
- Display: TFF color display (160x128 DPI)
- Resistor range: 0.1 ohm ~ 200 kilohm
- Power supply mode: car battery provides power 12.0 or 24.0V
- Diode range: 0.2V~2.6V
- Frequency range: 10HZ-200KHZ
- Trip current: 8AMPS for 1 hour, 12AMPS for less than 1 hour, 16AMPS for less than 5SEC
- Working voltage: 6-30V
- Cable length: 6 meters
- Supported languages: English, Spanish, German, French, Italian, Portuguese, Polish, Japanese, Korean
- Automatic detection of voltage, resistance, and diode without mode selection
- Reduces diagnosis time for 6 to 30 volt vehicle electrical systems
- Flexible testing of voltage, frequency, duty cycle, and injector
- Automatically draws waveform signals
- Can activate fuel pumps, solenoids, blowers, cooling fans, and headlights
- Circuit breaker with short-circuit protection function
- Dimensions: 165x40x27mm
