2 PCS HR1688 Quartz Clock Mechanism Movement,Spec: 32mm/ 24mm
2 PCS HR1688 Quartz Clock Mechanism Movement,Spec: 32mm/ 24mm
Duties & Import Tax
UK orders under £135 incur no additional fees. Otherwise, duties are only included if shown at checkout — your local government may apply customs fees, which your courier will collect directly from you before delivery.
Processed in 1–3 business days
No se pudo cargar la disponibilidad de retiro
UK: Free tracked shipping on every order, no minimum spend.
Everywhere else: Add the product to your cart and use the shipping calculator to see exact methods, rates, and delivery times for your country.
Fast refunds: Once we receive and inspect your return, your refund is processed to your original payment method within 5 business days.
Return postage: Just changed your mind? You'll need to cover the return postage. If the item arrived faulty, we'll cover the cost to get it back to us.
Product Details
HR1688 Quartz Clock Mechanism Movement is designed for DIY clock projects. It provides low noise operation and a long service life.
- Product type: DIY Clocks
- Compatibility: HR1688 quartz clock mechanism
- Material: Nylon
- Key feature: Low noise and long service life
- Intended use: Everyday use
- Movement gear made of high quality nylon material
- Electronic coil with high-quality bright copper lacquer wire winding
- Stator piece made of nickel-iron materials
- High magnetic permeability and low resistivity for power-saving
- Crystal frequency: 32.768KHz
- Time accuracy: +/-30Sec/Month (1.5V DC, 25 degrees Celsius)
- Current consumption: Less than 130μA (1.5V DC)
- Operating voltage: 1.3v to 1.7v
- Operating temperature: -10 to 50 degrees Celsius
- Power supply: 1.5v AA batteries (batteries not included)
- Weight: approximately 25g/PC
- Second hand output torque: less than or equal to 0.6gf-cm (1.5V)
- Minute hand output torque: less than or equal to 30gf-cm (1.5V)
- Pointer specification requirements:
- -Second hand length/weight: less than or equal to 130mm, less than or equal to 2g
- -Minute hand length/weight: less than or equal to 200mm, less than or equal to 6g
- -Second hand unbalance torque: less than or equal to 0.15gf-cm
- -Minute hand unbalance torque: less than or equal to 6gf-cm
- Movement battery slot generally not equipped with a battery cover
- Includes gold hexagonal plane nut, gold washer, black rubber pad
